Textron Bunton EC Hydro Midsize 930024 User Manual

GB-12
EC
Hydro
Midsize
6. Remove belt cover and set aside.
7. Block the rear of the cutterdeck with the
appropriate height block for the desired height of
cut B. See Support Block Chart below.
GNITTUC
THGIEH
ELOH
NONOITISOP
ENIGNE
*KCED
KCOLB
TATHGIEH
FORAER
)B(KCED
"526.1-"573.15"52.1
"573.2-"578.14"00.2
"521.3-"526.23"57.2
"578.3-"573.32"05.3
"526.4-"521.41"52.4
elohtsehgihehtsi1noitisoP*
.kcedenigneehtno
8. Position the power unit behind the cutterdeck.
9. Move the power unit towards the cutterdeck until
the guide pins A engage the appropriate hole C
on the power unit for the desired height of cut.
Fasten with (4) M12-1.75 X 30 bolts at D.
10. Loop the PTO belt E around the electric clutch
pulley. Using a 3/8" ratchet wrench or 3/8"
breaker bar rotate the PTO belt idler while looping
the PTO belt around the cutterdeck pulley.
11. Reinstall belt cover and fasten in place with
nuts F previously removed.
12. Remove support block from the rear of
cutterdeck.
13. Remove support from the rear of the power unit.
ASSEMBLY/SET-UP INSTRUCTIONS
