GB-23
EC
Hydro
Midsize
TRACKING WIDTH ADJUSTMENT
The tracking width originally set from the factory can
be increased an additional 83 mm overall by
performing the following steps.
1. Loosen wheel lug nuts on both drive tires.
2. Raise rear of unit so that drive tires are off the
ground. Support the unit with jack stands.
3. Remove wheel lug nuts and wheels. Reattach
wheels with the tires rotated so the wheel offset is
the opposite of when they were previously
installed. Reinstall and tighten lug nuts until they
are snug.
4. Lower machine off of the jack stands and torque
wheel lug nuts to 115 Nm.
TIRE PRESSURE ADJUSTMENT
Tire pressures should be maintained at 1.0 kg/cm
2
.
ADJUSTMENTS
