THERMAL INNOVATIONS (UK) LTD | THERMAFLOW® ELECTRIC COMBINATION BOILER | Tel: 0870 850 5207
5
(Additional Information given in G3 of the building regulations for discharge pipes)
0.2 Draining & Filling
CAUTION: THE THERMAFLOW BOILER WORKS IN A PRESSURISED SYSTEM WHICH
MUST ONLY BE DRAINED, REFILLED AND PRESSURISED BY A COMPETENT PERSON.
There are two drain taps fitted to the Thermaflow boiler, one to drain the potable circuit within the boiler
and one to drain the primary circuit within the boiler both drain taps are located at the bottom of the
appliance. Further drain taps should be fitted into the pipe-work at the lowest point of the potable water
circuit and the heating circuit and should terminate outside the dwelling in a suitable position.
0.3 Manual Handling Guidance
During the appliance installation it will be necessary to employ caution and assistance whilst
lifting as the appliance exceeds the recommended weight for a one man lift.
DO NOT LIFT THE APPLIANCE BY ATTACHED PIPE-WORK OR COMPONENTS
In certain situations it may be required to use a mechanical handling aid.
Take care to avoid trip hazards, slippery or wet surfaces.
IMPORTANT INFORMATION
0.4 TESTING & CERTIFICATION
The boiler is tested and certified for safety and performance. It is therefore important that no alteration
is made to the boiler, without permission, in writing, from Thermal Innovations (UK) Ltd.
Any alteration not approved by Thermal Innovations (UK) Ltd, could invalidate the certification, boiler
warranty and may also infringe the current issue of the statutory requirements, see section 2.1.2
The unit should be stored in a dry environment and should be handled with care to prevent attached
components being damaged or connections becoming loose.
All connections should be checked for
leaks after installation
.
0.5 THE UNIT LOCATION
The unit should be preferably located in a cupboard with a minimum dimension of;
L 800 mm x B 750 mm H 2.1m for the
TH9/21OU & TH12/210U.
L 800 mm x B 750 mm X H2.4M for
TH9/250U & TH12/250U
L. 820 mm x B. 750 mm x H. 2.4M for the TH9/330U & TH12/330U.
The floor to which the unit is placed upon should be capable of withstanding a load of:
270KG for the
TH9/21OU & TH12/210U
315KG for the TH9/250U & TH12/250U
405KG for the TH9/330U & TH12/330U.
The unit should be positioned in a manner that allows access to all components for future
maintenance. If located in a cupboard the unit should be positioned with all components facing
the entrance to allow elements to be replaced if required or any of the other components.
