SECTION 3: DESCRIPTION 12 Manual 0-2745
10. Overall Dimensions
Overall dimensions are with Handle, Lead Wrap
Bracket, and Gas Regulator/Filter Assembly installed.
19" (482 mm) High x 13" (330 mm) Wide x 24.8" (63
m) Long
B. Gas Regulator/Filter Assembly
Specifications
The following specifications apply to the Gas Regulator/
Filter Assembly only:
1. Gas regulator maximum gauge pressure
160 psi (11 bar)
2. Maximum input gas pressure
125 psi (8.6 bar)
3. Filter
Coalescent type filter
3.04 Power Supply Options and
Accessories
NOTE
Refer to Section 6, Parts Lists, for part numbers
and ordering information.
The following are some of the accessories that are avail-
able for this power supply. Refer to Section 6.09 for a
complete list:
A. Dry Air In-Line Filter Kit
An optional in line filter for use on compressed air
shop systems. Highly effective at removing moisture
and particulate matter from the air stream to at least
.85 microns.
B. Two Stage Air Line Filter
An alternative to the Dry Air Filter, this optional two
stage air line filter is for use on compressed air shop
systems. The filter will remove moisture and contami-
nants from the air stream to at least 5.0 microns. The
filter assembly is pre-assembled at the factory and
need only be attached to the power supply.
C. High Pressure Regulators
High pressure regulators are available for air and ni-
trogen. The regulators are used to set the proper pres-
sure for the type gas being used.
D. Smart Cart
Steel cart on easy rolling 10" pneumatic tires to pro-
vide maximum mobility for the power supply. Handle
is 3/4" tubing with hooks for storage of torch leads.
A tie down strap is also included.
E. 575V Transformer
This step-down transformer allows the power sup-
ply to operate with 575 VAC three-phase input power.
F. Computer Control Cable (CNC)
NOTE
This accessory is for use with PCM-40 Torches
only.
This interface cable is available in two lengths, 25 ft
(7.6 m) and 50 ft (15.2 m). The cable is used to inter-
face the power supply with an auxiliary control de-
vice to provide OK-To-Move and ON/OFF signals.
G. Cutting Guide Kit
Easy add-on attachments to allow for straight line,
circle, or bevel cutting.
H. Hand Pendant Control
A hand pendant control with 25 ft (7.6m) cable which
provides ON/OFF signals to the power supply.
Also offered is a 25 ft (7.6m) extension cable which
can be added to the hand Pendant Control cable to
provide a total length of 50 ft (15.2m).
