23
ERROR CODES
When an error has occurred, an error code is displayed on the LED display. The panel does
not turn to the display sleep mode while the error code is shown.
Figure 14 Error Code Example
After a component is replaced or the inspection is completed, turn the breaker on/o several
times to confirm the error does not re-occur.
NOTE:
After a component is replaced or the inspection is completed, turn the unit on/o
several times to confirm the error does not re-occur.
If the corrective action does not solve the error problem, a malfunction of the PCB is
highly likely
Figure: Error code display
