119

Remote Evaporator Specifications

Refrigeration System

Evaporator Coil Type Direct Expansion

Refrigerant Type R-404A

Heat/Defrost Method Hot Gas

Electrical

Control System Voltage 12.5 Vdc

Circuit Breaker CB1—Zone 2 Fan Motors 30 amp, auto reset

Circuit Breaker CB2—Zone 3 Fan Motors 30 amp, auto reset

Fuse F12—Zone 3 Fan Motors 25 amp

Fuse F13—Zone 3 Solenoids 15 amp

Fuse F15—Zone 2 Fan Motors 25 amp

Fuse F16—Zone 2 Solenoids 15 amp

Fan Motors (each):

Power Rating 0.13 hp (100 Watts)

rpm 2390

Full Load Amps 7 amps (per motor)

Remote Liquid Line Solenoid:

Current Draw 1.3 amps

Resistance 9.6 ohms

Remote Hot Gas Solenoid:

Current Draw 1.5 amps

Resistance 8.3 ohms

Remote Suction Line Solenoid:

Current Draw 1.5 amps

Resistance 8.3 ohms
