Thermoplan Black&Whute3 CT - 4.7 CBTM Front View

REV-1
6.22
© 2011 by Thermoplan AG, Änderungen vorbehalten
SECTION 6
Technical manual
Connection
Hydraulic module
Main switch
Hydraulic clip
Hydraulic clip
Cleaning
Cleaning
Check valveTea
Brew
Brew
(not used)
Hydraulic clip
Cleaning
key
Connection
Brew module
Connection mechanical module
CPU Mechanical clip
4.7 CBTM Front view
4. Chassis
