Thinkware Q850 - Part Names; Front Camera (Main Unit) - Front View

Product overview
7
1.2 Part names
1.2.1 Front camera (main unit) - front view
DC-IN power port
Used to connect the
power cable.
V-IN input port
Used to connect the
rear camera (optional).
Speaker
Outputs the voice guide and buzzer
sounds to indicate the product’s status.
GPS LED
Indicates the GPS
connection status.
Power button
Press and hold to turn off the product.
Press to turn on the product.
Format button
Press and hold to
format the memory
card.
Wi-Fi button
Press and hold for 3 seconds to connect the
product to a smartphone via Wi-Fi network.
REC button
•
Press to start manual recording.
• Press and hold for 3 seconds for SOS recording.
Voice recording button
Press to enable or disable voice recording.
Recording LED
Indicates the
recording status.
Wi-Fi LED
Indicates the Wi-Fi
connection status.
• To reset the product, press and hold the voice recording ( ) and REC ( ) buttons simultaneously until
you hear beeps.
• The security LED status may vary depending on the selected mode.
• Refer to the following table to check the status of the product using the LED indicators.
For more information about the REC LED, refer to "3.3 Using the continuous recording feature" on page 17.
LED LED status Operation description
BT/WiFi
(light on) Wi-Fi connected
(light on) / (flickers)
Bluetooth on/Bluetooth pairing
> >
(flickers)
Bluetooth/Wi-Fi reset
(light on) Internet Mode connected
GPS
(light on) GPS connected
Misc.
Wi-Fi
>
REC
>
GPS (flickers)
Firmware upgrade
