3
Page
4 Operation 34
4.1
Connections of the power unit
Connecting the earth cable
Connecting the welding gun
36
36
37
4.2 Chuck preparation 38
4.3 Adjusting the C0 and C1 guns 40
4.4 Adjusting the CHP (For future applications) -
4.5 Tips for good welding results 42
4.6 Work procedure during welding 43
4.7
Testing the weld
Visual inspection
Impact bending test
45
45
46
5 Maintenance 47
5.1 Troubleshooting 48
5.2 Care and cleaning 52
5.3 Maintenance intervals 53
5.4 Fuse elements 54
5.5 Technical specifications NOMARK 65 / 99 55
5.6 Explosion view of NOMARK 65 / 99 56
5.7 Block circuit diagram 58
5.8
Technical specifications C0 Gun
59
5.9 Explosion view 60
5.10 Welding accessories 63
5.11
Technical specifications C1 Gun
65
5.12 Explosion view 66
5.13 Welding accessories 68
5.14 Iso Kit for C1 71
5.15 Blank page for notes 73
