5.5 Technical specifications
Power unit : NOMARK 65 / 99
Welding method tip ignition in contact welding
Input voltage / Frequency NOMARK 65 / 99 (230 V)
230V(±10%) / 50Hz-60Hz
(see chapter 3.7)
NOMARK 65 / 115 V
115V(±10%) / 50Hz-60Hz
(see chapter 3.7)
Mains fuse external NOMARK 65 (230 V) : T 6.3 A
NOMARK 99 (230 V) : T 10 A
NOMARK 65 (115 V) : T 10 A
Charge capacity max NOMARK 65 : 66.000 µF
NOMARK 99 : 99.000 µF
Charge voltage 40 to 200 V, continuously adjustable
Fuses:
Mains voltage 10A / 250V
Cooling fan (AF)
Protective system IP 21
Protection class I (one)
Dimension (l x w x h)
400 mm x 195 mm x 270 (315) mm
Weight NOMARK 66 : 12,5 Kg
NOMARK 99 : 14 kg
Power cable length: 3 m
line cross section: 3 x 2,5 mm2
Earth cable (standard)
Earth cable including
1 plug and 2 clamps length 2.5 m.
cross section: 2 x 25 mm2; highly
flexible
