Item Article no. Part /description Qty
1. 650.668 Panel mounting weld socket 2
2. 101.002 Panel plug link “U” bar 1
3. 101.003 Knob cap 1
4. 101.004 Knob 1
5. 101.005 Control Panel overlay (NOMARK 65) 1
or 101.040 Control Panel overlay (NOMARK 99) 1
6. 101.006 Negative bus bar 1
7. 101.007 Mounting Pillar 2
8. 101.008 Free wheel diode 1
9. 101.009 Mains On/Off switch 1
10. 101.010 Earth screw 1
11. 101.011 Strain Relief 1
12. 101.012 Cord set (230V) 1
13. 101.013 Fuse holder 1
122.987 T 6.3 A Fuse (Not shown) NOMARK 65 / 230 V 1
or 100.014 T 10 A Fuse (Not shown) NOMARK 65 / 115 V 1
or 100.014 T 10 A Fuse (Not shown) NOMARK 99 / 230 V 1
14. 101.014 Main filter 1
15. 101.015 Positive bus bar 1
16. 101.016 Insulator Nut 4
17. 101.017 Thermal switch for fan control (NOMARK 65) 1
or - No Thermal switch (NOMARK 99) 0
18. 101.018 Fan 1
19. 101.019 Resistor (NOMARK 65) 4
or 101.019 Resistor (NOMARK 99) 5
20. 101.020 Mounting plate 1
or 101.061 Mounting plate NOMARK 65 / 115 V 1
101.062 Terminal Block NOMARK 65 / 115 V 1
21. 101.021 Welding SCR (NOMARK 65) 1
or 101.050 Welding SCR (NOMARK 99) 1
101.051 SCR Box clamp (NOMARK 99) 1
101.052 SCR Mounting plate (NOMARK 99) 2
101.053 Positive connection cable 1
22. 101.022 Control & Display PCB (NOMARK 65)
Fuse F2 : T 6.3 A
1
or 101.022 Control & Display PCB (NOMARK 99)
Fuse F2 : T 10 A
1
23. 101.023 Main transformer (NOMARK 65) 1
or 101.060 Main transformer (NOMARK 65 / 115V) 1
or 101.054 Main transformer (NOMARK 99) 1
24. 101.024 33.000 µF capacitors (NOMARK 65) 2
or 101.024 33.000 µF capacitors (NOMARK 99) 3
25. 101.025 PCB Connector 1
26. 101.026 Casing foot 4
27. 101.027 Housing base plate 1
28. 101.028 Panel mounting control socket 1
29. 101.029 Housing cover screw 12
30. 101.030 Housing cover 1
31. 101.031 Carrying handle 1
57
Tab: 5 - 19 Replacement parts list NOMARK 65 / 99
