Spare parts for C1 gun
Item Part number
Description
Quantity
1.
102.301
Chuck Nut 1
2.
102.302
Bellow 1
3.
102.303
Bellow retainer 1
4.
102.304
Bearing bush 1
6.
102.306
Spindle 1
7.
102.307
Screw 1
8.
102.308
Fixed spring seat 1
9.
102.309
Main spring 1
11.
102.311
Screw 1
12.
102.312
Adjustable spring seat 1
13.
102.313
Shaft Key 1
16.
102.316
Rear back cap 1
21.
190.002
Tripod Leg 3
22.
102.322
Front end cap / Legs holder
(Supplied without leg)
1
23.
102.323
Back cap & front end cap Screws 3+2
24.
102.324
Gun body moulding (2 parts) 1
31.
102.331
Screw 3
32.
102.332
Trigger button 1
33.
102.333
Trigger bezel 1
34.
102.334
Cable securing clip 1
36.
102.336
Screw 2
37.
102.337
Trigger switch 1
38.
102.338
Screw 2
39.
102.339 Flexible braid assembly
1
41.
102.341
Split washer 1
42.
102.342
Screw 1
60.
102.360
Ring 1
80.
102.380
Label “C1” 1
102.381
Label “THOMAS Welding Systems” 1
90.
102.390
Complete Cable assy’ ( 5 meters) 1
91.
102.391
Control cable sleeve 1
92.
102.392
Weld cable sleeve 1
93.
102.393
Cable splicing block 1
94.
102.394
Cable tie clip 10
96.
110.314
Cable end control plug 1
97.
110.020
Cable end weld plug 1
106.
110.232
Control cable (m) 5,3
107.
110.213
Weld cable (m) 5
67
Fig. 5 - 26 Explosion view contact pistol C1
