LIST OF ELECTRIC COMPONENTS
ZIP 22 - Single-phase 400 Volt 50Hz. / 110 Volt 60 Hz. dd 12/03/2012.
Ref. Description Technical Data Qty Make Code
FU1 Fuse Cartridge 2 Pole 32A 600V 1 Weber PCH 2X38
Fuse, Line Protection 10X38 16A 600V 2 Weber CH10X38 16A AM
FU2 Fuse Cartridge 1 Pole 32A 600V 1 Weber PCH 1X38
Fuse, Aux. Protection 10X38 1A 600V 1 Weber CH10X38 1A AM
TC1 Transformer 30VA OUT 24 V 1 F.M.T. P 0/110 60 Hz S24
C.M. Pole Commutator 20A 690V 1 Giovenzana P0200003R010
KM1 Remote Switch 25A NO 24VAC 1 A.B. 100-C23KJ10
KA Aux. Relay 1 CONTACT 250V 6A 1 FINDER ART 403180024 VAC
- Base, Finder Relay for FINDER Relay 1 FINDER ART. 40-9563
S.B. 2 Push-Button, Light 1 A.B. AB 800 LF7
HL1 Pilot Light 2W BAS 9 1 REER 30V. 2 WATT
SB1 Emergency Push-Button with Lock 1 A.B. 800FP-MT 44
" Base, Push-Button D.22 2 A.B. 800F-ALP
" Contact N.C. 10A 600V. 1 A.B. 800F-X01
SB2 Contact N.O. 10A 600V. 1 A.B. 800F-X10
SQ1 Micro-switch, sawframe protection 8A 400V. 1 Q.k.S 8
SQ2 Micro-switch, Gripswitch 4A 250V. 1 CROUZET E.F. 83161.1
M1 Motor, Blade Drive kW 0,91400rpm 1 TESSARO FC B 14 80 IP54
M2 Motor, Electropump kW 0,05 H85 single-phase 1 SAP SH2 IP54
X1 Terminals, connection Section 2,5 twin 2 A.B.
Plastic Box, Elettrocablaggi 230E0009/10 1 STANPLAST
Film, Control Panel 220X0340 1 Tecnotarghe 220X0340
RIF. Gear-Box 1/15 80 B14 1 S.T.M. RMI 50
C. Condenser 50mf/31mf 1+1 TESSARO
