Chapter 2
802.11 Standards
21
Range
802.11b is usually used in a point-to-multipoint configuration, in which an access point communicates via an
omni-directional antenna with one or more wireless stations that are located in a coverage area around the
access point. Typical indoor range is 30 m at 11 Mbps and 90 m at 1 Mbps. With (high-gain) directional
external antennas, the protocol can also be used in fixed point-to-point arrangements, typically at ranges up
to 8 km.
By using directional antennas you can enlarge the range of your network.
EMEA
(100 mW EIRP maximum)
2.2 50
5.2 30
630
8.5 5
12 5
13.5 5
Japan
(10 mW/MHz EIRP maximum)
2.2 30
5.2 30
630
8.5 N/A
12 N/A
13.5 5
Israel
(100 mW EIRP maximum)
2.2 50
5.2 30
630
8.5 5
12 5
13.5 5
Regulatory Domain Antenna Gain (dBi) Maximum Power Level (mW)
i
The use of directional antennas is regulated country by country. Check the local regulations before
using directional antennas.
