16. MENU Displays the main menu
17. Exits the menu or submenu and cancels the current function, if necessary
18. V + / V- Increase / decrease the volume level of the terminal
19. P + / P- Used to go to the next / previous channel
20. CH + / CH- Change the program for the previous / next program if there is no menu
21. 0 ~ 9 Key control and direct channel change
22. TV / R Switches between TV and RADIOmodes.
23No function
24. 2 Starts “Pause live TV” recording
25. 5 Fast rewind during playback
26. 6 Fast forward during playback
27 . 4 Records the television program on the connected storage device
P4
YOUR TERMINAL
28. 1 Start playing the selected file in the media player 29. 7 No function
30. 8 No function
31. 3 Stop playing the file selected in the media player
32. OPT Opens the settings for TV Format, Aspect Ratio and resolution
33. TEXT Display he teletext page, if applicable
34. SUB Displays the list of subtitle languages available for the current channel.
Displays the list of teletext languages available for the current
channel
35. Gives access to operator messages
2.4 Battery installation
Fig. 4
Remove the remote control compartment cover and insert 2 AAA batteries. The diagram inside
the remote control compartment shows the correct way to place the batteries. 1. Remove the
cover 2. Position the batteries 3. Close the cover
NOTE: Batteries should not be recharged, shorted, mixed or used with other types of
batteries.
2.5 Using the remote control
Fig. 5
Point the remote control at the digital terminal. The remote control has a range of up to 7
m from the terminal with an angle of up to 60 degrees.
3.0 CONNECTIONS
3.1 TV connection
Connection via HDMI cable
Fig. 6
Connect the HDMI output of the terminal to the HDMI input of the TV with an HDMI cable.
Connection with a scart or RCA cable
Fig. 6
Connect the TV scart connector on the back of the terminal to the scart connector (scart
input) on your television.
3.2 Connection to the digital audio amplifier
Fig. 6
Connect the S / PDIF connector on the back of the terminal to the corresponding input
on your amplifier 3.3 Connecting the satellite dish to the terminal
