P16
7. MAIN MENU
7.1.1.2 DiSEqC 1.2 set-up
Use this menu to configure the motor position for each satellite which you want to receive. If you have already
configured satellites, use tu in the PAGE (1/8-8/8) selection which will help you navigating easier through the
32 available positions. Select a position number and press OK to open its setup.
Satellite Press OK to open the list of available satellites and choose a satellite with pq or P+/P-
and confirm by pressing OK.
Transponder Press OK to open the list of available transponders if you need to adjust a transponder
for the above selected satellite.
Movement Speed: Here you can change the motor speed Slow/Quick.
Move: Press tu to move the dish to East or West. Carefully move it until you can observe
that both signal bars receive acceptable reception levels. When you have found the
selected satellite press
and select Yes to save the position.
Centre Position: Press OK to move the motor to the centre position of 0 degrees. This is only needed for
the first time to adjust the dish correctly.
Set Limit: Press OK to open this submenu in order to adjust mechanical limits for your dish. This
is only necessary if your dish is damaged due to touching a wall or similar mechanical
margins.
7.1.1.3 GOTO X set-up
Use this menu to configure the motor position through the GOTO-X function. If you have already configured
satellites, use tu in the PAGE (1/8-8/8) selection which will help you navigating easier through the 32 available
positions. Select a position number and press OK to open its setup.
Satellite Press OK to open the list of available satellites and choose a satellite with pq or P+/P-
and confirm by pressing OK.
Transponder Press OK to open the list of available transponders if you need to adjust a transponder
for the above selected satellite.
Your longitude: Use the 0 ~ 9 buttons to enter the value of your longitude. Press OK to confirm the
value.
Your latitude: Use the 0 ~ 9 buttons to enter the value of your latitude. Press OK to confirm the value.
GOTO: Press OK to move the motor to the wanted position according to your local
parameters. Press
and select Yes to save this position.
Center Position: Press OK to move the motor to the centre position of 0 degrees. This is only needed for
the first time to adjust the dish correctly.
NOTE: Detailed information about correct values for your location can be found on websites like
dishpointer.com, itouchmap.com or other reliable sources.
7.1.1.4 SAT Edit
This submenu allows renaming of the chosen satellite or creating a new satellite position. Use pq to choose
Satellite or Position.
Satellite: Press OK to open the keyboard and enter a new name with the 0 ~ 9 buttons (max. 9
signs). When you have entered the preferred name, press pq to choose OK in order
to rename or choose Cancel to discard.
Position: Use 0 ~ 9 to enter the orbital position. If necessary, you can use OK and pq to change
the hemisphere from E to W or vice versa.
By pressing the pq buttons you can select OK to change or Cancel to discard.
7.1.1.5 New TP
This submenu allows adding one or more transponders to the database of the selected satellite. This enables
you to check the signal or adjust the antenna for this satellite. Further you can perform a NIT Search on the
