Rev: 1.1, 22-Jun-2023 © 2023 Thorlabs
Page 27
PM103x Optical Power Meter Interfaces Chapter 4 Operating Instructions
4.3 Software
The PM103x is operated remotely from a PC, laptop or tablet.
Thorlabs OPM Software
The Thorlabs Optical Power Monitor (OPM) software provides a Graphical User Interface to view, log,
and analyze measurement data. Download the OPM software package Version 5.0 or higher from the
Thorlabs website, via this link, through the software tab on the product website, or through searching
for the product name within the Thorlabs software website.
All information on software installation, device control and data management software can be found in
the software manual directly downloaded here.
Note
Do not connect the PM103x prior to software installation!
Attention
Exit all running applications on your PC as the installer may require a reboot of your PC during
installation!
Custom Made Software
The PM103x can also be run using custom made software. For this, please refer to the document Write-
Your-Own-Application (WYOA) for PM103x.
4.3.1 Software Requirements
All models of the PM103x can be run with the Thorlabs' OPM software version 5.0 or higher.
Please find the requirements for the PC intended to be used for operation of the PM103x on the OPM
website.
4.3.2 PM103x Specific Software Functions
When using a PM103x power meter interface, the OPM software version 5.0 (or higher) shows several
power meter specific functions. To see details, please also visit the OPM manual.
4.3.2.1 PM103 Specific Software Functions
1. When a PM103x power meter is connected, the OPM software recognizes NTCs in the devices
section. The OPM now allows users to adjust settings, view measurement results and to integrate
the NTC measurement results in long-time monitoring experiments. For more information, please
see the OPM manual.
2. When a PM103 or a PM103E is connected, it is possible to configure the analog AO2 port and display
the output voltage.
4.3.2.2 PM103A Specific Software Functions
When a PM103A is connected, it is possible to configure the analog AO2 SMA port and display the
output voltage.
When using the “Scope Modein the OPM software, the digital I/O SMA port can be used as an external
trigger or as a monitor output for the internal trigger.
