Page 4 MTN023788_D02
PM103x Optical Power Meter Interfaces Chapter 2 General Information
2.2 Ordering Codes and Accessories
PM103
Power and Energy Meter Interface with DA-15 Connector; USB, RS232, or UART
Operation. Digital or Analog Signal Output; Two Digital I/O Ports; NTC Input; USB
Interface for Control and Power Supply.
PM103A
Power and Energy Meter Interface with SMA Connectors for two Analog Outputs and one
Digital I/O Port; USB Interface for Control and Power Supply.
PM103U
Power and Energy Meter Interface with USB Connector and USB Operation for Control,
Read Out, and Power Supply.
PM103E
Power and Energy Meter Interface with Ethernet Connector for Control and Power
Supply (Power over Ethernet, PoE) and Phoenix DMC Connector 0,5/7 with RS232
Interface, Two Digital Configurable In/Outputs, Two Analog Outputs; NTC Input, and
Connection for External Power Supply.
Included Accessories:
The PM103x Power and Energy Meters include certain cables. Further cables are recommended in
Optional Accessories .
PM103: DA-15 Connector and Connector Housing
USB Cable, Type A to Mini B, with locking screw, 1.5 m
PM103A: USB Cable, Type A to Mini B, with locking screw, 1.5 m
PM103U: USB Cable, Type A to Mini B, with locking screw, 1.5 m
PM103E: RJ45 Patchcable 1.5 m,
Phoenix DFMC Connector with 2x7 pins: DFMC 0,5/ 7-ST-2,54 - PCB connector
Optional Accessories:
To run the PM103x power and energy meter, additional cables or mounting devices may be required.
Cables
· PM103: Cable to attach to the provided DA-15 connector housing.
· PM103A: SMA cable: please provide a cable with a SMA connector for your PM103A.
Thorlabs offers a variety of SMA connector cables.
· PM103E: Wires (AWG 26-20; 0.14 mm² - 0.5 mm²) to connect with the DFMC 0,5/7 push-in
spring contacts.
· CABRU15: Adapter Cable: USB to Serial Flying Leads, 60'' (1.5 m) long. Suitable for PM103E,
PM101R, and PM5020, and any device with an RS232 interface to adapt it to a USB
interface.
Mounting
· Horizontal Mounting Clamp (ECM225) to mount the PM103x onto a post.
· Vertical Mounting Clamp (ECM100) to mount the narrow side of the PM103x onto a post.
4
