PM103x Optical Power Meter Interfaces Chapter 2 General Information
· Double Sided Horizontal Mounting Clamp (EPS225) to securely mount two devices on top of each
other.
Please visit our homepage http://www.thorlabs.com for various accessories like power and energy
sensors, fiber adapters, posts and post-holders.
2.3 Requirements
Hardware Requirements
PM103: Please provide an appropriate cable to be attached to the DA-15 connector.
PM103A: Please provide appropriate cables to connect to the SMA ports.
PM103E: Please provide an appropriate cable to be attached to the Phoenix DMC connector,
(DMC 0,5/7).
Software Requirements
All models of the PM103x can be run with the Thorlabs' OPM software. Please see the requirements for
the OPM on the website.
Sensor Requirements
Thorlabs C-Series Sensors
The PM103x supports all Thorlabs C-Series photodiode and pyroelectric sensors. The C-Series can be
easily identified by the red connector-housing of the DE-9 connector, compared to older versions of
Thorlabs power sensors.
Please refer to the chapter Connecting a Power Sensor on how to use older Thorlabs sensors or
custom sensors.
