Page 30 MTN023788_D02
PM103x Optical Power Meter Interfaces Chapter 5 Specifications
PM103
PM103A
PM103U
Supported Temperature Sensor
Thermistor NTC
0.1 - 100 k ,
B-Value:
1000 - 9999 K
NA
NA
Temperature Measurement Range
-40 °C to +200 °C
(NTC dependent)
NA
NA
Digital Control Pins I/O
Connector
DA-15 Pins 2/3
SMA
NA
Function
2 x GPIO
or Configurable as
Trigger Input/Output,
Pass/Fail Analysis
GPIO or Configurable
as Trigger
Input/Output
NA
Power Management
DC Input 1 / Connector
+5 VDC to +36 VDC /
DA-15 Pins 1, 9
NA
NA
DC Input 2 / Connector
5 V / USB
Power Consumption
1 W
Display
Display Type
None; External PC - Windows Application or Driver Set
Display Screens
Windows Application Software Provided
GUI Refresh Rate
1000 Hz (Dependent on PC and Settings)
General
Detectors Compatibility
Photodiode Sensors S100C Series
Energy Sensors ES100C, ES200C Series
Photodiodes (Max 10 mA)
Pyro Detectors (Max 200 V)
Status LED
Power, Sensor, PGM Error, USB
Operating Temperature
0 °C to +40 °C
Storage Temperature
-40 to 70 °C
Dimensions (L x W x H)
3.80" x 2.25" x 1.00"
(96.5 x 57.2 x
25.4 mm
3
)
3.94" x 2.25" x 1.00"
(100.2 x 57.2 x
25.4 mm
3
)
3.68" x 2.25" x 1.00"
(93.6 x 57.2 x
25.4 mm
3
)
Weight
0.15 kg (0.33 lb)
