Page 32 MTN023788_D02
PM103x Optical Power Meter Interfaces Chapter 5 Specifications
Item #
PM103E
Temperature Measurement
Range
-10 to 80 °C
Sensor Power Supply
Connector
DE-9 Pin 1
Voltage
5V
Maximum Current
50 mA
Remote Interfaces
Remote Interface Type 1
Ethernet
Connector
RJ45
Measurement Speed
1 kS/s + 100 kS/s bulk mode
Remote Interface Type 2
RS232
Connector
Phoenix DMC 0,5/7 PIN 3 and PIN 4
Baud Rate
9600 - 256000 Bit/s
Default: 115200 Bit/s
Settings
N1S
Measurement Speed
200 sps + 100 kS/s bulk mode
Analog Output AO2, Configurable
Connector
Phoenix DMC 0,5/7, PIN 11
Signal
Gain Signal Configurable
Voltage Range
0 to 2.5 V
Accuracy
±1%
Bandwidth
1 kHz
Analog Output AO1, Not Corrected
Connector
Analog , Phonix DMC 0,5 /7, PIN 13
Signal
Amplified Input Signal - Not Corrected
Voltage Range
-0.25 V to 2.5 V
Accuracy
±3%
Bandwidth
up to 1 MHz, Dependent on Sensor and Settings
Auxiliary Temperature Measurement
Connector
Phoenix DMC 0,5/7, PIN 9
Supported Temperature Sensor
Thermistor NTC
0.1 - 100 k ,
B-Value:
1000 - 9999 K
Temperature Measurement
Range
-40 °C to +200 °C
(NTC dependent)
Digital Control Pins I/O
Connector
Phoenix DMC 0,5/7, PINs 5 and 7
Function
2 x GPIO
or Configurable as Trigger Input/Output, Pass/Fail Analysis
GPIO or Configurable as Trigger Input/Output
Power Management
Power over Ethernet
RJ45 connection
Alternative DC Input
+5... +36VDC, Phoenix DMC 0,5/7 PIN 1 and 2 (GND)
Power Consumption
1 W
