LDC401 & LDC401A Automated Cleavers Chapter 10: Accessories
Page 48 TTN100064-D02
Transfer Inserts, if desired, while the right Fiber Holding Block of the LDC401A is incompatible with the Transfer
Inserts, due to the presence of the Rotation Stage.
Item #
Transfer
Insert
Side 1 Min/Max
Accepted Diameter
Side 2 Min/Max
Accepted Diameter
Vacuum
Holes
VHD080
No 57 µm / 100 µm N/A Yes
VHD125
No 88 µm / 161 µm N/A Yes
VHD160
No
112 µm / 208 µm N/A Yes
VHF160
Yes
VHD250
No
177 µm / 320 µm N/A Yes
VHF250
Yes
VHD400
No
279 µm / 519 µm N/A Yes
VHF400
Yes
VHD500
No
346 µm / 795 µm N/A Yes
VHF500
Yes
VHD750
No
516 µm / 1047 µm N/A Yes
VHF750
Yes
VHE10
No 773 µm / 1271 µm 1034 µm / 1523 µm No
VHE15
No 1280 µm / 1769 µm 1534 µm / 2007 µm No
VHE20
No 1787 µm / 2267 µm 2033 µm / 2513 µm No
VHE25
No 2270 µm / 2844 µm N/A No
VHE30
No 2692 µm / 3198 µm N/A No
Insert Selection Guide
The table on the following page indicates the maximum and minimum diameters that can be accommodated by
different combinations of Top and Bottom Inserts. It also indicates how far offset the fiber will be for recommended
combinations of Top and Bottom Inserts. Note that the fiber outer diameter may be the fiber cladding, jacket, or
buffer. If one side of the fiber is being discarded, it is preferable to clamp onto the cladding of this section except in
special cases (such as non-circular fiber) where the coating or buffer may be preferable. Sections of fiber that are
not being discarded should always be clamped on the coating or buffer in order to avoid damaging the glass. This
may require different sets of fiber holder Inserts to be used in the left and right holding blocks. In this case, it is
important to minimize the difference in the offsets introduced by the left and right sets of Inserts when attempting to
produce perpendicular, flat cleaves.
