Fiber Holder Insert Selection Chart
Top Insert Item #
V
HA00
10
V
HA05
10
V
HA10
10
V
HA15
10
V
HA20
10
V
HA25
10
V
HA30
10
Accepted Diameter
(Nominal)
≤320
µm
400 µm 500 µm 750 µm 1000 µm 1250 µm 1500 µm 1750 µm 2000 µm 2250 µm 2500 µm 3000 µm
Bottom
Insert Item
#
Accepted
Diameter
(Nominal)
Min/Max Accepted Diameter (µm)
Min/Max Offset (µm)
VHD080
11
80 µm
57/100
-23/21
VHD125
11
125 µm
88/161
-37/36
V
HD160
11
or
VHF160
11,12
160 µm
112/208
-49/48
- - - - - - - - - - -
V
HD250
11
or
VHF250
11,12
250 µm
177/320
-73/69
275/323
25/74
- - - - - - - - - -
V
HD400
11
or
VHF400
11,12
400 µm
279/519
-
122/119
377/517
-23/117
410/519
-9/119
- - - - - - - - -
V
HD500
11
or
VHF500
11,12
500 µm
346/592
-153/93
447/647
-53/147
476/711
-24/211
560/795
61/296
- - - - - - - -
V
HD750
11
or
VHF750
11,12
750 µm
516/759
-234/9
617/970
-
132/221
643/878
-107/128
728/963
-23/213
812/1047
62/297
- - - - - - -
VHE10
10
1000 µm
- -
773/1008
-172/63
858/1093
-88/147
943/1178
-3/232
1036/1271
90/325
- - - - - -
1250 µm
- - -
1034/1269
-176/59
1119/1354
-91/144
1212/1447
2/237
1288/1523
78/313
- - - - -
VHE15
10
1500 µm
- - - -
1280/1515
-172/63
1373/1608
-79/156
1449/1684
-2/233
1534/1769
82/314
- - - -
1750 µm
- - - - -
1534/1770
-159/76
1611/1846
-83/152
1695/1930
2/237
1772/2007
78/313
- - -
VHE20
10
2000 µm
- - - - - -
1787/2022
-171/64
1871/2106
-86/149
1947/2183
-10/225
2032/2267
74/309
- -
2250 µm
- - - - - - -
2033/2268
-167/68
2109/2344
-91/144
2193/2429
-6/229
2278/2513
78/313
-
VHE25 2500 µm
- - - - - - - -
2270/2505
-172/64
2355/2590
-87/148
2439/2675
-2/233
2609/2844
167/402
VHE30 3000 µm
- - - - - - - - -
2692/2944
-256/-4
2777/3029
-171/81
2946/3198
-2/250
Legend
Best Fit
Second Best Fit
Try these options if the best fit does not
incorporate your fiber sizes.
Third Best Fit
Try these options if the other two categories do not
incorporate your fiber sizes.
Figure 64 Each Insert Can Hold a Range of Fiber Sizes
Here are instructions for using the charts on the previous page.
1. First, select the Bottom Insert that matches your fiber size most closely.
Example: For an Ø800 µm fiber, the VHD750 insert is the closest match, since it is only 50 µm smaller.
2. On the chart below, look to the right of your chosen Bottom Insert. Select a compatible Top Insert
based on the fiber diameter size range shown in each cell.
10
These Inserts have two grooves, one on each side, that each accommodate a different range of fiber sizes, except for the VHA00, which
has a flat surface on one side that can be used to clamp the smallest fiber sizes.
11
These Bottom Inserts have vacuum holes to aid in aligning small fibers when used with the large-diameter fiber Cleavers.
12
These are transfer Inserts. When used with the VHT1 Transfer Clamp, they allow the fiber to be transferred between compatible stripping,
cleaning, Cleaving, splicing, and tapering stations without losing registration of the fiber tip location relative to the edges of the fiber holding
block.
