Parts!No. Description Item!No. Description quantity Reference
Assemble!Step
BK0093 Linkage Rod (L=45) 3 17
BK0094 Linkage Rod (L=60) 2 17
BK0095 Linkage Rod (L=76) 2 17
PV0048 Pitch Frame/
Rotor Hub Seesaw Brg.
HMV840ZZ Bearing, d4xD8xW3 2 6
PV0049 Seesaw Brg. HMV830ZZ Bearing, d4xD8xW4 2 11
PV0051 Leaver Brg. HMV740ZZ Bearing, d4xD7xW2.5 4 5
PV0052 Tail Slider Brg. HMV1060 Bearing, d6xD10xW3 2 13
PV0053 Rotor Bolt. HMC4-27B Cap Screw, M4x27 2 20
HMM4Z Lock Nut, M4 2 20
PV0054 Servo Mounting Plate BK0104 Servo Mounting Plate 10 16
PV0056 Frame Spacer (L) BK0058 Frame Spacer (L) 5 3
PV0057 Frame Spacer (S) BK0059 Frame Spacer (S) 10 3
PV0058 Link Ball BK0075 Linkage Ball 12 5
PV0059 Tail Shaft Brg. HMV1150 Bearing, d5xD11xW5 2 13
PV0060 Installation Set BE1052 Antenna Tube 1 18
BK0106 Double Side Tape 2 18
BK0109 Rubber Band 5x3 20xT1 2 18
HNI15 Hex Wrench 1.5mm 1 1
HNI2 Hex Wrench 2mm 1 1
HNI25 Hex Wrench 2.5mm 1 1
HNI3 Hex Wrench 3mm 1 1
HNJ-1 Tie Band 2.5x100 3 8
PV0062
Body Mount Rubber Grommet
BK0102 Body Mount Rubber 5 19
PV0092 Swash Plate BV0092 Metal Swash Plate 1 7
PV0093 Main Shaft Bearing HMV1680 Bearing, d8xD16xW5 1 2
HMV6800 Bearing, d10xD19xW5 2 6
PV0107 Engine Mount (.50) BK0087 Washer 4 9
BK0144 Engine Mount 1 9
BK0179 Engine Mount Spacer 2 9
HMC3-14 Socket Screw 8 9
PV0109 High Performance BA1579 Muffler Gasket 1 9
Muffler (.46-.50) MV0172 Muffler 1 9
HMC3-35B Socket Screw 2 9
HMT3B Spring Washer 2 9
PV0118 Main Rotor Blades BV0176 Main Rotor Blade 1 20
PV0148 Tail Rotor Grip BK0302-1 Tail Pitch Housing (A) 2 13
BK0303-1 Tail Pitch Housing (B) 2 13
HMC2610B Socket Screw, M2.6x10 4 13
HMM26B Lock Nut, M2.6 4 13
HMC3-14B Socket Screw, M3x14 2 13
HMM3B Lock Nut, M3 2 13
PV0151 Tail Rotor Hub BK0307 Tail Rotor Hub 1 13
HME3-18B Set Screw, M3x18 2 13
HMM3B Lock Nut, M3 2 13
PV0200 Tail Rotor Brg. HMV1050 Bearing, d5xD10xW5 4 13
PV0203 Starter Shaft Brg. HMV696Z Bearing, d6xD15xW5 2 3
PV0267 Loctite #242 1
PV0268 Loctite #262 1
PV0270 Plastic Gear Grease 1
PV0279 Tail Rod Guide BK0091 Rod Guide 3 14
PV0311 Header Tank BK0087 Washer 1 15
BK0102 Rubber Grommet 1 15
