39
Parts!No. Description Item!No. Description quantity Reference
Assemble!Step
BK0506 Header Tank Support 1 15
BK0502 Header Tank 1 15
HMC3-14B Socket Screw 1 15
PV0326 Carbon Graphite Base Plate BK0525 Carbon Graphite Base Plate 1 10
PV0329 Tail Support BK0447 Tail Support Rod End 4 14
BK0524 Tail Support Rod 2 14
HMJ2-8N Selftapping Screw, M2x8 4 14
PV0353 Main Rotor Grip BK0075 Linkage Ball 2 11
BK0596 Main Pitch Housing 2 11
HMJ2-10N Selftapping Screw, M2x10 2 11
PV0354 Main Rotor Hub BK0587 Main Rotor Pin 1 11
BK0616 Socket Screw, M3x20 1 12
BV0595 Main Rotor Hub 1 11
HMM3Z Lock Nut, M3 1 12
PV0355 Spindle BK0581 Flap Collar 2 11
BK0583 Feathering Shaft 1 11
BK0435 Washer, d4xD11x1.7 2 11
HMC4-8B Socket Screw, M4x8 2 11
PV0358 Clutch Bell BV0591 Clutch Bell Set 1 2
PV0359 Clutch BK0170 Shim 1 8
BV0589 Clutch Bell Set 1 8
HMC3-10B Socket Screw, M3x10 2 8
PV0360 Starter Shaft BK0592 Starter Shaft 1 3
HME4-5B Set Screw, M4x5 2 3
HMS5 E-Clip 1 3
PV0361 Starter Coupling BK0594 Starter Coupling 1 3
HME4-5B Set Screw, M4x5 2 3
PV0362 Main Frame Set BK0058 Frame Spacer (L) 4 3
BK0059 Frame Spacer (S) 8 3
BK0599 Main Frame Left Side 1 3
BK0600 Main Frame Right Side 1 3
HMC3-20B Socket Screw, M3x20 4 15
HMM3Z Lock Nut, M3 4 15
HSE3-12B Selftapping Screw, M3x12 24 3
PV0363 Fuel Tank BV0605 Fuel Tank Set 1 1
PV0364 Body BK0098 Body Clip A 1 19
BK0099 Body Clip B 1 19
BK0102 Rubber Grommet 2 19
BK0611 Body 1 19
BK0612 Canopy 1 19
HSE3-12B Selftapping Screw, M3x12 2 19
PV0365 Thrust Brg. HMX0612 Thrust Bearing 2 11
PV0368 Clutch Liner BK0590 Clutch Liner 2 2
PV0369 Canopy Only BK0612 Canopy 1 19
HMJ2-6B Selftapping Screw, M2x6 6 19
PV0370 Body Only BK0098 Body Clip A 1 19
BK0099 Body Clip A 1 19
BK0611 Body 1 19
BK0102 Rubber Grommet 2 19
HSE3-12B Selftapping Screw, M3x12 2 19
PV0372 Thrust Collar BK0584 Thrust Collar 2 11
PV0373 Clutch Bell Brg. HMV1260Y Bearing, d6xD12xW4 2 2
PV0374 Feathering Brg. HMV1260Z Bearing, d6xD13xW5 2 11
To Next Page
