PPAARRTTSS CCHHEECCKK LLIISSTT
Tail Gear Set
Tail Gear x 1
Tail Wheel x 1
Collar x 1
3x3mm Set Screw x 2
3x12mm Wood Screw x 1
3x16mm Wood Screw x 1
Control Horn
Control Horn x 5
Backplate x 5
2 x14mm Screw x 15
M2 Nut x 7
Dia. 2.2mm Clevis x 1
Dia. 1.7mm Clevis x 4
Metal Clevis x 2
2x8mm Screw x 5
Ball x 5
EZ Connector
Connector x 1
M2 Nut x 1
M2 Washer x 2
3x3mm Set Screw x 1
Allen Wrench x 1
Fuel Tank
Tank x 1
Clunk x 1
Nipple x 1
90-degree Nipple x 1
Fuel Stopper x 1
Fuel Tube x 1
Cap x 1
Kit Contents:
Main Wing
One-Piece Main Wing x 1
Wing Mounting Plate x 1
Dowel x 2
CA Hinge x 8
Doubler x 1
Retainer x 4
Horizontal Tail
Horizontal Tail x 1
Elevator (Left/1, Right/1)
CA Hinge x 4
Vertical Tail
Rudder x 1
CA Hinge x 3
Fuselage
Fuselage x 1
Bottom Section x 1
Spinner
Spinner x 1
Backplate x 1
3x16mm Self-Tapping Screw x 4
Pushrod
Throttle Pushrod x 1
Guide Tube(1)
Aileron Pushrod(M) x 2
Rudder Pusherod(2.2mm) x 2
Pushrod (S) x 2
Elevator Pushrod(L) x 2
Main Landing Gear
Landing Gear Strut x 1
3x3mm Set Screw x 4
Collar x 4
Dual Linkage System
Tube x 1
Shaft x 1
Control Arm x 2
3x3mm Set Screw x 2
Decal
Fire Decal x 2
Logo Decal x 1
Screw Set
3x22mm Screw x 4
M3 Nut x 4
M3 Wahser x 6
3x15mm Wood Screw x 4
3x8mm Wood Screw x 10
3x35mm Wood Screw x 2
Wheel x 2
Engine Cowl x 1
Canopy x 1
Manual x 1
