OPERATING MANUAL 4. MOUNTING OF MACHINE
ThyssenKrupp Aufzugswerke GmbH 40 Issue 06.2004
4.5 Schematic diagram DAF270
Winding
Temperature
monitoring
Brake magnet
Control switch
Encode
r
Motor Brake
Temperature
monitoring
+M
