OPERATING MANUAL 2. TRANSPORT AND STORAGE
ThyssenKrupp Aufzugswerke GmbH 10 Issue 06.2004
2. Transport and storage
Packing:
DAF270 is delivered:
a) without machine frame; assembled on a wooden pallet and wrapped in foil.
b) machine and frame assembled and wrapped in foil; wooden edges or a
special pallet screwed below the machine frame.
Remove these transport contrivances before you install the machine on
site.
Transport:
Machine and frame must be perfectly horizontal and the safety precautions
observed.
Transport by means of fork lift:
• The forks must be of proper length to prevent the machine from tilting.
• See to it that the forks are attached to the frame or transport pallet and
not to the machine.
• Pay attention to projecting parts! There is the risk of injury to persons or
damage!
Transport by crane:
• Do not stay below suspended loads!
• Fasten transport chains or ropes at the machine frame.
See to it that the machine is perfectly horizontal.
• Fasten at transport aid and secure against tilting. Do not lift the motor
housing!
• Remove transport aids after transport.
Note the pictographs fastened on the packing or other visible places.
Top Handle with care Keep dry
Do not expose to
heat
Do not use handheld
grippers
Fasten here
