FUNCTION CHARACTERISTICS
121
NA30 - Manual - 04 - 2022
Example: to change the first threshold of the definite time overcurrent element 50/51 within CLP dur-
ing a 0.1 s time interval:
• the ICLP> Mode parameter must be set as ON-Change setting,
• the tCLP> parameter must be adjusted to a wanted value (0.1 s) inside the Set \ Profile A(or B)\
Phase overcurrent - 50/51\ I> Element \ Setpoints menu,
• The threshold within CLP parameter ICLP>def must be adjusted to a wanted value inside the Set
\ Profile A(or B)\ Phase overcurrent - 50/51\ I> Element \ Definite time menu.
CB position can be acquired by means one or two binary inputs; allocation of 52a and 52b func-
tions is available inside the Set \ Inputs \ Binary input1(x) menu.
