IN11 matching
Reset LEDs | Set profile | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 |
TCS2 | Trip ProtExt | Reset counters | Reset CB
Monitor | 52a | 52b | Open CB | Close CB | Preset
DTheta | Remote trip | Reset on demand measu-
res | 74VT ext. | None
Binary input IN12
IN12
Logic Active-ON | Active-OFF
IN12 tON
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN12 tOFF
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN12 matching
Reset LEDs | Set profile | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 |
TCS2 | Trip ProtExt | Reset counters | Reset CB
Monitor | 52a | 52b | Open CB | Close CB | Preset
DTheta | Remote trip | Reset on demand measu-
res | 74VT ext. | None
Binary input IN13
IN13
Logic Active-ON | Active-OFF
IN13 tON
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN13 tOFF
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN13 matching
Reset LEDs | Set profile | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 |
TCS2 | Trip ProtExt | Reset counters | Reset CB
Monitor | 52a | 52b | Open CB | Close CB | Preset
DTheta | Remote trip | Reset on demand measu-
res | 74VT ext. | None
Binary input IN14
IN14
Logic Active-ON | Active-OFF
IN14 tON
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN14 tOFF
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN14 matching
Reset LEDs | Set profile | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 |
TCS2 | Trip ProtExt | Reset counters | Reset CB
Monitor | 52a | 52b | Open CB | Close CB | Preset
DTheta | Remote trip | Reset on demand measu-
res | 74VT ext. | None
Binary input IN15
IN15
Logic Active-ON | Active-OFF
IN15 tON
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN15 tOFF
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
