APPENDIX
197
NA30 - Manual - 04 - 2022
IN15 matching
Reset LEDs | Set profile | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 |
TCS2 | Trip ProtExt | Reset counters | Reset CB
Monitor | 52a | 52b | Open CB | Close CB | Preset
DTheta | Remote trip | Reset on demand measu-
res | 74VT ext. | None
Binary input IN16
IN16
Logic Active-ON | Active-OFF
IN16 tON
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN16 tOFF
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN16 matching
Reset LEDs | Set profile | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 |
TCS2 | Trip ProtExt | Reset counters | Reset CB
Monitor | 52a | 52b | Open CB | Close CB | Preset
DTheta | Remote trip | Reset on demand measu-
res | 74VT ext. | None
Binary input IN17
IN17
Logic Active-ON | Active-OFF
IN17 tON
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN17 tOFF
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN17 matching
Reset LEDs | Set profile | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 |
TCS2 | Trip ProtExt | Reset counters | Reset CB
Monitor | 52a | 52b | Open CB | Close CB | Preset
DTheta | Remote trip | Reset on demand measu-
res | 74VT ext. | None
Binary input IN18
IN18
Logic Active-ON | Active-OFF
IN18 tON
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN18 tOFF
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN18 matching
Reset LEDs | Set profile | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 |
TCS2 | Trip ProtExt | Reset counters | Reset CB
Monitor | 52a | 52b | Open CB | Close CB | Preset
DTheta | Remote trip | Reset on demand measu-
res | 74VT ext. | None
Binary input IN19
IN19
Logic Active-ON | Active-OFF
IN19 tON
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN19 tOFF
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
