NA30 - Manual - 04 - 2022
IN19 matching
Reset LEDs | Set profile | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 |
TCS2 | Trip ProtExt | Reset counters | Reset CB
Monitor | 52a | 52b | Open CB | Close CB | Preset
DTheta | Remote trip | Reset on demand measu-
res | 74VT ext. | None
Binary input IN20
IN20
Logic Active-ON | Active-OFF
IN20 tON
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN20 tOFF
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN20 matching
Reset LEDs | Set profile | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 |
TCS2 | Trip ProtExt | Reset counters | Reset CB
Monitor | 52a | 52b | Open CB | Close CB | Preset
DTheta | Remote trip | Reset on demand measu-
res | 74VT ext. | None
Binary input IN21
IN21
Logic Active-ON | Active-OFF
IN21 tON
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN21 tOFF
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN21 matching
Reset LEDs | Set profile | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 |
TCS2 | Trip ProtExt | Reset counters | Reset CB
Monitor | 52a | 52b | Open CB | Close CB | Preset
DTheta | Remote trip | Reset on demand measu-
res | 74VT ext. | None
Binary input IN22
IN22
Logic Active-ON | Active-OFF
IN22 tON
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN22 tOFF
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN22 matching
Reset LEDs | Set profile | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 |
TCS2 | Trip ProtExt | Reset counters | Reset CB
Monitor | 52a | 52b | Open CB | Close CB | Preset
DTheta | Remote trip | Reset on demand measu-
res | 74VT ext. | None
Binary input IN23
IN23
Logic Active-ON | Active-OFF
IN23 tON
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN23 tOFF
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
