Thytronic NA30

APPENDIX
204
NA30 - Manual - 04 - 2022
IN43 matching
Reset LEDs | Set profile | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 |
TCS2 | Trip ProtExt | Reset counters | Reset CB
Monitor | 52a | 52b | Open CB | Close CB | Preset
DTheta | Remote trip | Reset on demand measu-
res | 74VT ext. | None
Binary input IN44
IN44
Logic Active-ON | Active-OFF
IN44 tON
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN44 tOFF
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN44 matching
Reset LEDs | Set profile | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 |
TCS2 | Trip ProtExt | Reset counters | Reset CB
Monitor | 52a | 52b | Open CB | Close CB | Preset
DTheta | Remote trip | Reset on demand measu-
res | 74VT ext. | None
Binary input IN45
IN45
Logic Active-ON | Active-OFF
IN45 tON
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN45 tOFF
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN45 matching
Reset LEDs | Set profile | Fault trigger | Block2
IPh/IE | Block2 IPh | Block2 IE | Block1 | TCS1 |
TCS2 | Trip ProtExt | Reset counters | Reset CB
Monitor | 52a | 52b | Open CB | Close CB | Preset
DTheta | Remote trip | Reset on demand measu-
res | 74VT ext. | None
Relays
K1
Logic De-energized | Energized
Operation MODE No-latched | Pulse | Latched
Minimum pulse width ms 0 ... 500 step = 5
K2
Logic De-energized | Energized
Operation MODE No-latched | Pulse | Latched
Minimum pulse width ms 0 ... 500 step = 5
K3
Logic De-energized | Energized
Operation MODE No-latched | Pulse | Latched
Minimum pulse width ms 0 ... 500 step = 5
K4
Logic De-energized | Energized
Operation MODE No-latched | Pulse | Latched
Minimum pulse width ms 0 ... 500 step = 5
K5
Logic De-energized | Energized
Operation MODE No-latched | Pulse | Latched
Minimum pulse width ms 0 ... 500 step = 5
K6
Logic De-energized | Energized
Operation MODE No-latched | Pulse | Latched
Minimum pulse width ms 0 ... 500 step = 5
