APPENDIX
205
NA30 - Manual - 04 - 2022
K7
Logic De-energized | Energized
Operation MODE No-latched | Pulse | Latched
Minimum pulse width ms 0 ... 500 step = 5
K8
Logic De-energized | Energized
Operation MODE No-latched | Pulse | Latched
Minimum pulse width ms 0 ... 500 step = 5
K9
Logic De-energized | Energized
Operation MODE No-latched | Pulse | Latched
Minimum pulse width ms 0 ... 500 step = 5
K10
Logic De-energized | Energized
Operation MODE No-latched | Pulse | Latched
Minimum pulse width ms 0 ... 500 step = 5
LEDs
START
Type No-latched | Latched
TRIP
Type No-latched | Latched
L1
Type No-latched | Latched
L2
Type No-latched | Latched
L3
Type No-latched | Latched
L4
Type No-latched | Latched
L5
Type No-latched | Latched
L6
Type No-latched | Latched
L7
Type No-latched | Latched
L8
Type No-latched | Latched
L9
Type No-latched | Latched
L10
Type No-latched | Latched
Analog outputs
Current loop 1
Loop 1 Measure assigned Loop1-Mis
Frequency | IL1 | IL2 | IL3 | IE | IL | UE | I1 | I2 | PLC
| None
Loop 1 Output range Loop1-Range
0-2 mA | 0-4 mA | 0-5 mA | 1-5 mA | 0-6 mA | 1-6
mA | 0-10 mA | 4-20 mA
Loop 1 Sign Loop1-Sign Unipolar | Bipolar
Loop 1 Nominal multiplier Loop1-M 0.01 ... 100.00 step = 0.01
Current loop 2
Loop 2 Measure assigned Loop2-Mis
Frequency | IL1 | IL2 | IL3 | IE | IL | UE | I1 | I2 | PLC
| None
Loop 2 Output range Loop2-Range
0-2 mA | 0-4 mA | 0-5 mA | 1-5 mA | 0-6 mA | 1-6
mA | 0-10 mA | 4-20 mA
Loop 2 Sign Loop2-Sign Unipolar | Bipolar
Loop 2 Nominal multiplier Loop2-M 0.01 ... 100.00 step = 0.01
Current loop 3
Loop 3 Measure assigned Loop3-Mis
Frequency | IL1 | IL2 | IL3 | IE | IL | UE | I1 | I2 | PLC
| None
