I>>inv Operating time t>>inv s 0.02 ... 10.00 step = 0.01
I>>> Element
Setpoints
I>>> Enable I>>> Enable OFF | ON
ICLP>>> Mode ICLP>>> Mode OFF | ON - Element blocking | ON - Change setting
ICLP>>> Activation time
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
I>>> Reset time delay
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
I>>> Logical block I>>>BLK1 OFF | ON
I>>> Input selective block I>>>BLK2IN OFF | ON
I>>> Output selective block I>>>BLK2OUT OFF | ON
I>>> Internal selective block I>>>BLK4 OFF | OUT | IN
I>>> Second harmonic restraint I>>>2ndh-REST OFF | ON
I>>> Breaker failure I>>>BF OFF | ON
I> Disabling by I>>> start I>disbyI>>> OFF | ON
I>> Disabling by I>>> start I>>disbyI>>> OFF | ON
I>>> Start relays I>>>ST-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
I>>> Trip relays I>>>TR-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
I>>> Start LEDs I>>>ST-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
I>>> Trip LEDs I>>>TR-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
Definite time
50/51 Third threshold definite time
State OFF | ON
Pickup value In
0.100 ... 0.999 step = 0.001
1.00 ... 9.99 step = 0.01
10.0 ... 40.0 step = 0.1
I>>>def within CLP ICLP>>>def In
0.100 ... 0.999 step = 0.001
1.00 ... 9.99 step = 0.01
10.0 ... 40.0 step = 0.1
I>>>def Operating time
Value s 0.03 ... 10.00 step = 0.01
Residual overcurrent - 50N/51N
IE> Element
Setpoints
IE> Enable IE> Enable OFF | ON
IE> Curve type IE>Curve
IEC/BS A | IEC/BS B | IEC/BS C | ANSI/IEEE MI |
ANSI/IEEE VI | ANSI/IEEE EI | EM | DEFINITE
IECLP> Mode IECLP> Mode OFF | ON - Element blocking | ON - Change setting
IECLP> Activation time
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
tE> Reset time delay
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IE> Logical block IE>BLK1 OFF | ON
IE> Input selective block IE>BLK2IN OFF | ON
IE> Output selective block IE>BLK2OUT OFF | ON
IE> Internal selective block IE>BLK4 OFF | OUT | IN
IE> Second harmonic restraint IE>2ndh-REST OFF | ON
IE> Breaker failure IE>BF OFF | ON
IE> Start relays IE>ST-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
IE> Trip relays IE>TR-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
IE> Start LEDs IE>ST-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
IE> Trip LEDs IE>TR-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
