Definite time
50N/51N First threshold definite time
State OFF | ON
Pickup value IEn
0.002 ... 0.999 step = 0.001
1.00 ... 10.00 step = 0.01
IE>def within CLP IECLP>def IEn
0.002 ... 0.999 step = 0.001
1.00 ... 10.00 step = 0.01
IE>def Operating time
Value s
0.04 ... 9.99 step = 0.01
10.0 ... 99.9 step = 0.1
100 ... 200 step = 1
Inverse time
50N/51N First threshold definite time
State OFF | ON
Pickup value IEn
0.010 ... 0.999 step = 0.001
1.00 ... 2.00 step = 0.01
IE>inv within CLP IECLP>inv IEn
0.010 ... 0.999 step = 0.001
1.00 ... 2.00 step = 0.01
IE>inv Operating time tE>inv s
0.02 ... 9.99 step = 0.01
10.0 ... 60.0 step = 0.1
IE>> Element
Setpoints
IE>> Enable IE>> Enable OFF | ON
IECLP>> Mode IECLP>> Mode OFF | ON - Element blocking | ON - Change setting
IECLP>> Activation time
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
tE>> Reset time delay
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IE>> Logical block IE>>BLK1 OFF | ON
IE>> Input selective block IE>>BLK2IN OFF | ON
IE>> Output selective block IE>>BLK2OUT OFF | ON
IE>> Internal selective block IE>>BLK4 OFF | OUT | IN
IE>> Second harmonic restraint IE>>2ndh-REST OFF | ON
IE>> Breaker failure IE>>BF OFF | ON
IE> Disabling by IE>> start IE>disbyIE>> OFF | ON
IE>> Start relays IE>>ST-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
IE>> Trip relays IE>>TR-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
IE>> Start LEDs IE>>ST-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
IE>> Trip LEDs IE>>TR-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
Definite time
50N/51N Second threshold definite time
State OFF | ON
Pickup value IEn
0.002 ... 0.999 step = 0.001
1.00 ... 10.00 step = 0.01
IE>>def within CLP IECLP>>def IEn
0.002 ... 0.999 step = 0.001
1.00 ... 10.00 step = 0.01
IE>>def Operating time
Value s 0.03 ... 10.00 step = 0.01
IE>>> Element
Setpoints
IE>>> Enable IE>>> Enable OFF | ON
IECLP>>> Mode IECLP>>> Mode OFF | ON - Element blocking | ON - Change setting
IECLP>>> Activation time
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
tE>>> Reset time delay
