Thytronic NA30

APPENDIX
225
NA30 - Manual - 04 - 2022
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IE>>> Logical block IE>>>BLK1 OFF | ON
IE>>> Input selective block IE>>>BLK2IN OFF | ON
IE>>> Output selective block IE>>>BLK2OUT OFF | ON
IE>>> Internal selective block IE>>>BLK4 OFF | OUT | IN
IE>>> Second harmonic restraint IE>>>2ndh-REST OFF | ON
IE>>> Breaker failure IE>>>BF OFF | ON
IE> Disabling by IE>>> start IE>disbyIE>>> OFF | ON
IE>> Disabling by IE>>> start IE>>disbyIE>>> OFF | ON
IE>>> Start relays IE>>>ST-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
IE>>> Trip relays IE>>>TR-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
IE>>> Start LEDs IE>>>ST-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
IE>>> Trip LEDs IE>>>TR-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
Definite time
50N/51N Third threshold definite time
State OFF | ON
Pickup value IEn
0.002 ... 0.999 step = 0.001
1.00 ... 10.00 step = 0.01
IE>>>def within CLP IECLP>>>def IEn
0.002 ... 0.999 step = 0.001
1.00 ... 10.00 step = 0.01
IE>>>def Operating time
Value s 0.03 ... 10.00 step = 0.01
Residual overvoltage - 59N
Common configuration
59N Operation from 74VT external 74VText59N OFF | Block
UE> Element
Setpoints
UE> Enable UE> Enable OFF | ON
UE> Curve type UE>Curve INVERSE | DEFINITE
UE> Reset time delay
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
UE> Logical block UE>BLK1 OFF | ON
UE> Breaker failure UE>BF OFF | ON
UE> Start relays UE>ST-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
UE> Trip relays UE>TR-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
UE> Start LEDs UE>ST-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
UE> Trip LEDs UE>TR-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
Definite time
59N First threshold definite time
State OFF | ON
Pickup value UEn 0.01 ... 0.70 step = 0.01
UE>def Operating time
Value s
0.07 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
Inverse time
59N First threshold inverse time
State OFF | ON
Pickup value UEn 0.01 ... 0.50 step = 0.01
UE>inv Operating time tUE>inv s
0.10 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
UE>> Element
Setpoints
UE>> Reset time delay
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
