Thytronic NA30

APPENDIX
227
NA30 - Manual - 04 - 2022
State OFF | ON
Residual current pickup value IEn
0.002 ... 0.999 step = 0.001
1.00 ... 2.00 step = 0.01
Residual voltage pickup value UEn 0.004 ... 0.500 step = 0.001
Characteristic angle gr 0 ... 359 step = 1
Half operating sector gr 1 ... 180 step = 1
IED>inv within CLP IEDCLP>inv IEn
0.002 ... 0.999 step = 0.001
1.00 ... 2.00 step = 0.01
IED>inv Operating time tED>inv s
0.02 ... 9.99 step = 0.01
10.0 ... 60.0 step = 0.1
IED>> Element
Setpoints
IED>> Enable IED>> Enable OFF | ON
IED>> Curve type IED>>Curve
IEC/BS A | IEC/BS B | IEC/BS C | ANSI/IEEE MI |
ANSI/IEEE VI | ANSI/IEEE EI | EM | DEFINITE
IEDCLP>> Operating mode IEDCLP>> Mode OFF | ON - Element blocking | ON - Change setting
IEDCLP>> Activation time
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IED>> Reset time delay
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IED>> Logical block IED>>BLK1 OFF | ON
IED>> Input selective block IED>>BLK2IN OFF | ON
IED>> Output selective block IED>>BLK2OUT OFF | ON
IED>>>> Internal selective block IED>>BLK4 OFF | OUT | IN
IED>> Breaker failure IED>>BF OFF | ON
IED> Disabling by IED>> start IED>disbyIED>> OFF | ON
IED>> Start relays IED>>ST-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
IED>> Trip relays IED>>TR-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
IED>> Start LEDs IED>>ST-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
IED>> Trip LEDs IED>>TR-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
Definite time
Second threshold definite time
State OFF | ON
Residual current pickup value IEn
0.002 ... 0.999 step = 0.001
1.00 ... 10.00 step = 0.01
Residual voltage pickup value UEn 0.004 ... 0.500 step = 0.001
Characteristic angle gr 0 ... 359 step = 1
Half operating sector gr 1 ... 180 step = 1
IED>>def within CLP IEDCLP>>def IEn
0.002 ... 0.999 step = 0.001
1.00 ... 10.00 step = 0.01
IED>>def Operating time
Value s 0.05 ... 10.00 step = 0.01
Inverse time
Second threshold inverse time
State OFF | ON
Residual current pickup value IEn
0.002 ... 0.999 step = 0.001
1.00 ... 2.00 step = 0.01
Residual voltage pickup value UEn 0.004 ... 0.500 step = 0.001
Characteristic angle gr 0 ... 359 step = 1
Half operating sector gr 1 ... 180 step = 1
IED>>>>inv within CLP IEDCLP>>inv IEn
0.002 ... 0.999 step = 0.001
1.00 ... 2.00 step = 0.01
IED>>inv Operating time tED>>inv s 0.02 ... 10.00 step = 0.01
IED>>> Element
Setpoints
IED>>> Enable IED>>> Enable OFF | ON
IEDCLP>>> Operating mode IEDCLP>>> Mode OFF | ON - Element blocking | ON - Change setting
