IEDCLP>>> Activation time
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IED>>> Reset time delay
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IED>>> Logical block IED>>>BLK1 OFF | ON
IED>>> Input selective block IED>>>BLK2IN OFF | ON
IED>>> Output selective block IED>>>BLK2OUT OFF | ON
IED> Internal selective block IED>>>BLK4 OFF | OUT | IN
IED>>> Breaker failure IED>>>BF OFF | ON
IED> Disabling by IED>>> start IED>disbyIED>>> OFF | ON
IED>> Disabling by IED>>> start IED>>disbyIED>>> OFF | ON
IED>>> Start relays IED>>>ST-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
IED>>> Trip relays IED>>>TR-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
IED>>> Start LEDs IED>>>ST-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
IED>>> Trip LEDs IED>>>TR-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
Definite time
67N Third threshold definite time
State OFF | ON
Residual current pickup value IEn
0.002 ... 0.999 step = 0.001
1.00 ... 10.00 step = 0.01
Residual voltage pickup value UEn 0.004 ... 0.500 step = 0.001
Characteristic angle gr 0 ... 359 step = 1
Half operating sector gr 1 ... 180 step = 1
IED>>>def within CLP IEDCLP>>>def IEn
0.002 ... 0.999 step = 0.001
1.00 ... 10.00 step = 0.01
IED>>>def Operating time
Value s 0.05 ... 10.00 step = 0.01
IED>>>> Element
Setpoints
IED>>>> Enable IED>>>> Enable OFF | ON
IEDCLP>>>> Operating mode IEDCLP>>>> Mode OFF | ON - Element blocking | ON - Change setting
IEDCLP>>>> Activation time
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IED>>>> Reset time delay
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IED>>>> Logical block IED>>>>BLK1 OFF | ON
IED>>>> Input selective block IED>>>>BLK2IN OFF | ON
IED>>>> Output selective block IED>>>>BLK2OUT OFF | ON
IED>>>> Internal block IED>>>>BLK4 OFF | OUT | IN
IED>>>> Breaker failure IED>>>>BF OFF | ON
IED> Disabling by IED>>>> start IED>disIED>>>> OFF | ON
IED>> Disabling by IED>>>> start IED>>disIED>>>> OFF | ON
IED>>> Disabling by IED>>>> start IED>>>disIED>>>> OFF | ON
IED>>>> Start relays IED>>>>ST-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
IED>>>> Trip relays IED>>>>TR-K K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
IED>>>> Start LEDs IED>>>>ST-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
IED>>>> Trip LEDs IED>>>>TR-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 |
L9 | L10
Definite time
67N Fourth threshold definite time
State OFF | ON
Residual current pickup value IEn
0.002 ... 0.999 step = 0.001
1.00 ... 10.00 step = 0.01
