22
NOTE: It is recommended that the Bill Acceptor is manually cleaned
every thirty days or every 30,000 bills, whichever occurs first.
Step 1: Remove the Cassette from the Bill Acceptor.
Step 2: Open the “clamshell” by pressing the release button on the
front of the Bill Acceptor.
Step 3: Use compressed air to blow out the feed path and crevices
on the Bill Acceptor.
Step 4: Clean the rubber rollers and sensor lenses using a clean
cloth dampened with ethyl or isopropyl alcohol.
Step 5: Close the clamshell securely.
Step 6: Replace the Cassette onto the Bill Acceptor.
Bill Acceptor Manual Cleaning
(CashCode)
Clamshell opening button
Rollers (7) inside,
(2) behind clamshell
Sensors (10) inside
