Names and Functions of Component Parts
Lid
Heating plate
Lid gasket
Carrying handle
Used when carrying the
rice cooker
Center sensor
Inner pot
Upper casing
Lid open button
Push to open
the lid
Steam vent
Heater plate
Power plug
(Insert in an outlet)
Power cord
Appliance plug
(Insert in an appliance plug
inlet)
Appliance plug
inlet
Steam cap
Inner lid
Inner lid gasket
Inner lid button
Not removable.
Do not attempt to
remove.
(See P 32 to 33)
Not removable.
Do not attempt to
remove.
Tab
Lid sensor
Operation panel
[Hour] and [Min] keys
Used to set current time
and adjust Timer function.
[Menu] key
Used to select the desired cooking menu.
Keep Warm lamp
Lit when the Keep Warm
function is on.
[Keep Warm/Cancel] key
Used to keep rice warm
and to cancel the current
operation.
Display
Displays the
symbol (menu
cursor) and the current time, etc.
[Start] key
Used to start cooking rice and
food, etc.
• The small projections (
) on the [Start] and [Keep Warm/Cancel] keys are to aid persons with a visual impairment.
Start lamp
Lit during cooking, etc.

Checking the accessories
Spatula
COOKBOOK
Cooking plate
Exclusive measuring cup
Approximately 5.29 oz
The spatula
can be
placed on
rice cooker

For rst time use
■ Wash inner pot and accessories before using
them. (See P 31)

Sounds emitted by the rice cooker
The following sounds coming from the rice cooker
during cooking, steaming, or when the Keep Warm
function is on are normal and do not indicate a problem:
• Clicking sound (This is the sound of the
microcomputer controller.)
• Scraping sound (This is the sound of metal
contracting and rubbing together due to heat.)
• Sound like boiling water (Only during cooking or
steaming.)

Lithium battery
The rice cooker has a built-in lithium battery. It
stores the current time and the preset timer settings
even with the power plug disconnected.
• Ifthelithiumbatteryrunsout,“0:00”willblink
on the display when the power plug is plugged
back in. The rice cooker can still cook normally,
however, the current time, preset timer settings,
and elapsed Keep Warm time are deleted when
the power plug is disconnected.
Note
● Do not attempt to replace the lithium battery
yourself.
To replace the lithium battery, contact an
authorized service representative.

Checking the current time
The time is displayed in a 12-hour format. Adjust the
time if the correct time is not displayed. (See P 42)
[Timer] key
Used to set the timer.
Timer lamp
Lit or blinks when the
Timer function is set.
Lid hook
