5
Parts Inventory
Mini gangSTop
PART
DESCRIPTION
(NUMBER)
QUANTITY
Retention Block
(XMA4720)
2
Locking Handle
(LH)
2
M6 Hex Nut
(F2004)
2
M8x10mm Cap Screw
(F1935)
2
M8 Weld Nut
(F0406)
2
Stop Bar Tube & Plate
(M1021 & M4720-1)
1
PVC Foot
(B4700-2)
1
#10-14x1” Thread-forming
Screw
(F5004)
2
