TigerStop TS Series User Manual

38
Appendix A: Default Parameter Values
Menu Parameter Default Value
Motion
Stall MEP 2.000
Stall MES 2.000
Run MEP 2.000
Run MES .200
Brake Vel 32.000
Brake Gain 30.000
Find Vel 0.000
Find Trig 300.000
Timer
Clamp On Delay 100 ms
Saw On Delay 100 ms
DM O Time Out 5000 ms
Cycle Time Out 900,000 ms
TA O Time Out 5000 ms
DM On Time Out 5000 ms
Clamp O Delay 100 ms
Saw Cycle Delay 100 ms
RSD Ready Time
Out
2000 ms
Outfeed Delay 200 ms
Load Delay 0 ms
System
Info
Zero End Motor End
Set TIK None
Baud Rate 9600
I/O Panel Baud
Rate
9600
Motor Type Standard
Menu Parameter Default Value
Laser
Laser
Marking
O
Defect Only O
Laser Error .200 in
Laser Count 3
Laser Location Motor End
Laser Limit
Set to maximum
limit of TigerStop
at factory.
Laser Reference 5.000 in
Crayon O
PF Oset 29.250 in
IR Oset 1.950 in
PF Down 24.000 in
Debug Debug Mode O
