3
Parts Inventory
PART
DESCRIPTION
(NUMBER)
QUANTITY
Controller Stand Top
(M1803)
1
Square Tube
(M1808)
1
Round Tube
(M1807)
1
Controller Stand
Base Half-Bracket
(M10070)
2
M6x14mm
Socket-Head Screw
(F7216)
1
M6x10mm
Socket-Head Screw
(F7208)
1
M8x50mm
Hex-Head Screw
(F9827)
1
M8x45mm
Hex-Head Screw
(F9826)
2
conTroller STand aSSeMblY
