SYSTEM OVERVIEW: TS4-B
1. Modules with integrated TS4
2. Tigo Access Point (TAP)
3. Cloud Connect Advanced (CCA)
4. Inverter
8
1 2 43
access point
B A B A B A
AUX RS485-1 RS485-2GATEWAY POWER
