TW 160PH
HYDRAULIC LAYOUT
29 / 51
C190-0013 11.04.2019
CO73-105
BOTTOM
MOTOR
PUMP
TANK
CO73-104
CO73-103
CO73-102
CO73-100
CO73-101
FILTER
DCV
Hose kit No. CO73-106
TOP MOTOR
