Timberwolf TW 160PH - Parts Lists

TW 160PH
PARTS LIST
33 / 51
C190-0013 11.04.2019
Page No.
BELT TENSIONER 34
CHASSIS (1) 35
CHASSIS (2) 36
CONTROL BOX 37
DISCHARGE 38
DRIVE TRAIN 39
ELECTRICAL LAYOUT 40
ENGINE 41
FUNNEL 42
FUEL TANK 43
HYDRAULIC TANK 44
HYDRAULICS 45
ROLLER BOX 46
ROLLER SLIDES 47
ROTOR 48
ROTOR HOUSING 49
DECALS 50
THE FOLLOWING ILLUSTRATIONS ARE FOR PARTS IDENTIFICATION ONLY. THE REMOVAL OR FITTING OF THESE
PARTS MAY CAUSE A HAZARD AND SHOULD ONLY BE CARRIED OUT BY TRAINED PERSONNEL.
PARTS LISTS
