TW 160PH
2 / 51
C190-0013 11.04.2019
Serial No. Location
The serial number can
be found on the
identification plate
located on the chassis
beam.
Designed to chip solid wood material up to 150mm in diameter and capable of
chipping up to 3.5 tonnes of brushwood per hour.
DIMENSIONS
2108 mm (1248 mm with discharge removed)
3475mm (2935mm with feed tray folded)
1266mm
TIMBERWOLF TW 160PH SPECIFICATION
Engine type: Honda v‐twin petrol
Maximum power: 16.4kW (22hp)
Cooling method: Air cooled
Overall weight: 608kg
Starting method: Electric
Roller feed: Twin hydraulic motor
Max. diameter material: 152mm (6”)
Fuel capacity: 18 litres
Hydraulic oil capacity: 15 litres
Material processing capacity: 3.5 tonnes/hr
Fuel type: Unleaded petrol
THE TIMBERWOLF TW 160PH
