PK-232 – MBX OPERATING MANUAL COMMAND SUMMARY
4/91 A-22 147
K Toggles the PK-232's PTT and CW keying outputs between ON and OFF.
Q Quits the calibration routine.
H Toggles the generator between wide (1000 Hz) and narrow (200 Hz) shift.
<SPACE> Toggles the audio tone between "mark" (low) and "space" (high) tones.
D Toggles between transmitting a continuous tone or alternating the mark and space
tones at a rate set by the radio baud (HBAUD) rate.
FREQUENCY RESISTOR FUNCTION
2310 R164 HF SPACE, RTTY SPACE
2200 R165 VHF SPACE, WIDESHIFT SPACE
1200 R167 VHF MARK, CW AFSK, WIDESHIFT MARK
This tone should be adjusted before R168
2110 R168 HF MARK, RTTY MARK
CANline "n" Default: $18 <CTRL-X>
Mode: All Host: CL
Parameters: "n" - 0 to $7F (0 to 127 decimal) specifies an ASCII character code.
The parameter "n" is the ASCII code for the character you want to use to cancel an input line. You
can enter the code in either hex or decimal.
When you use the CANLINE character to cancel an input line in Command Mode, the line is termi-
nated with a <BACKSLASH> character and a new prompt (cmd:) appears. When you cancel lines
in Converse Mode, only a <BACKSLASH> and a new line appear.
o You can cancel only the line you are currently typing.
o Once <CR> or <Enter> has been typed, you cannot cancel an input line.
NOTE: If your send-packet character is not <CR> or <Enter>, the cancel-line char-
acter cancels only the last line of a multi-line packet.
CANPac "n" Default: $19 <CTRL-Y>
Mode: Packet, Command Host: CP
Parameters: "n" - 0 to $7F (0 to 127 decimal) specifies an ASCII character code.
The parameter "n" is the ASCII code for the character you want to type in order to cancel an input
packet or to cancel display output from the PK-232.
You can only cancel the packet that is being entered in CONVERSE Mode. When you cancel a pack-
et, the line is terminated with a <BACKSLASH> and a new line. You must cancel the packet before
typing the send-packet character.
In the COMMAND mode, this character cancels displayed output from the PK-232. Typing this char-
acter once cancels ALL output from the PK-232 to your display. Typing the cancel-output character
again restores normal output.
