PK-232MBX – OPERATING MANUAL INTRODUCTION
8/91 1-4 15
1.4.4 Controls and Indicators
Front Panel Controls: Power Switch
Radio Selector Switch
Threshold Adjust Potentiometer
Indicators: Ten-segment discriminator-type bargraph
Indicator for HF tuning
DCD LED (Data Carrier Detect)
Status & Mode Indicators: Mode Group Status Group
BAUDOT STBY
ASCII PHASE
PKT IDLE
MORSE ERROR/CONV
SELFEC OVER
FEC TFC/TRANS
ARQ RQ/CMD
MODE L CON
STBY STA
MULT
SEND
1.4.5 General
Power Requirements: +13 VDC (12 to 16 VDC) at 800 mA
Mechanical: Overall, 11" × 8.25" × 2.5"
(279.4 mm × 209.6 mm × 63.5 mm)
Weight 3 pounds (1.36 kilograms)
